$182.50

010"DIA HITACHI SUPER SOFT BRASS WIRE is made with a CuZn40 (60% copper, 40% zinc) brass alloy which, due to its higher zinc content, allows for faster cutting speed than brass wires made with a CuZn37 or CuZn35 alloy. It's well suited to run on Agies and other name brand machines.

For availability contact us via Chat, (800)290-7573, or at
[email protected]

Hitachi High Performance Brass EDM wire is made by Hitachi Metals in Japan. Hitachi is one of the best-known names in the EDM industry as a manufacturer of premium brass EDM wires. Hitachi's reputation is based on a level of consistency and quality in its product line and is unmatched by other brands in the industry. Both Fanuc and Makino recommend Hitachi as their brass wire of choice. Hitachi is also well suited to run on Agies and other name brand machines.
Only pristine, virgin raw materials are used in the manufacturing of Hitachi brass wire. It has virtually no paraffin which helps it to run very clean and without causing any brass build-up in the wire guide system. The use of natural diamond dies in the final drawing steps of the manufacturing process leads to a superior, extremely consistent and smooth wire surface.
Hitachi EDM wire is made with a CuZn40 (60% copper, 40% zinc) brass alloy which, due to its higher zinc content, allows for faster cutting speed than brass wires made with a CuZn37 or CuZn35 alloy.
Hitach Metals has a fully vertically integrated manufacturing line where casting, drawing, spooling and packaging of the product are all done internally; guaranteeing the highest quality control and consistency.

In line with Hitachi's ABZ product, the Hitachi ABZ-A wire is manufactured to a nominal tensile strength of 441 N/mm2. It features a higher elongation of > 25% which makes it especially suitable for wide-angle taper cuts of between 20° and 40°.

EDM Wire
Wire Core Brass 65/35
Wire Coating n/a
Elongation >25
Wire Diameter (in) .010
Wire Diameter (mm) 0.25
Tensile Strength (N/mm2) 441
Target Materials Steel
Flushing Conditions Average
Work-piece size/shape Taper/conical cut > 20°
Application Priority (speed vs precision) Precision and finish
Recommended Usage Aerospace, Precision Machining, Tool & Die, Molds, General Machining, Medical, Production EDM
Spool Type P5
Spool Weight (lb) 11
Spool Weight (kg) 5
Approximate Length/spool (yd) 12,795
Approximate Length/spool (m) 11,700
Packaging Quantity 4/box
Machine Manufacturer Makino
Fanuc
Seibu
Sodick
Agie
Mitsubishi
