$289.98

.010"DIA HYPERCUT WIRE, 22LBS is made in Germany by bedra and features a high zinc CuZn40 brass core and a special gamma-brass coating. This hybrid wire allows up to 20% faster cutting speed compared to standard brass wire with excellent surface finish as well as very high accuracy and precision. It also has superior cleanliness, excellent straightness and provides precise automatic threading and touch-off.

Available

bedra HyperCut EDM Wire is sold exclusively by Single Source Technologies and was developed in close collaboration between Makino and bedra.

It is made in Germany by bedra and belongs to a generation of new hybrid wires that combine key features of traditional γ-phase wires with traditional zinc coated wires. The result is up to 20% faster cutting speed compared to standard brass wire with excellent surface finish as well as very high accuracy and precision. HyperCut Wire is manufactured to the highest quality standards and due to its superior cleanliness and excellent straightness, it provides precise automatic threading and touch-off.


bedra HyperCut EDM Wire is made of a high zinc CuZn40 brass core and features a special γ-brass coating. It is drawn to a 900 N/mm2 tensile strength with 1% elongation. It is offered standard in .010" and .012" diameter on a variety of spools; however, it is available in other diameters upon request.


While originally developed for Makino machines, HyperCut has been proven to run exceptionally well on other machines such as Fanuc, Mitsubishi, or Sodick. bedra HyperCut is the go-to EDM wire for those who are looking for higher cutting speed while maintaining excellent surface quality at a competitive price.

EDM Wire
Wire Core Brass 60/40
Wire Coating Gamma brass
Elongation 1
Conductibility 24.1
Wire Diameter (in) .010
Wire Diameter (mm) 0.25
Tensile Strength (N/mm2) 900
Target Materials Steel, Copper, Tungsten carbide, Aluminum, Nickel, Titanium, PCD
Flushing Conditions Average to poor
Work-piece size/shape Medium tall parts < 6"
Application Priority (speed vs precision) Speed & High Precision
Recommended Usage Tool & Die, General Machining, Medical
Spool Type P10
Spool Weight (lb) 22
Spool Weight (kg) 10
Approximate Length/spool (yd) 25,591
Approximate Length/spool (m) 23,400
Packaging Quantity 2/box
Machine Manufacturer Makino
Mitsubishi
Fanuc
Sodick
Seibu

Product review summary

(1)Reviews
